CinemaSnap Screen

  • Pic 1

  • Pic 2

  • Pic 3

Market Segments

Suitable for use in Galleries
Suitable for Government use
Suitable for Home Entertainment
Suitable for Staging Production
Suitable for Sports
Suitable for Theatre use

Easy to install and never requires surface re-tensioning!

Sizes 72" - 225" diagonal

Setting the benchmark for perfect lay flat and ease of installation, this fixed screen is designed to complement modern home theatre design, using a dedicated wall space.

Benefits include:

  • Perfect lay flat
  • Easy to install
  • Contemporary design
  • No moving parts
  • Fire-rated surface

CinemaSnap - Unity White PVC

Sizes 72" - 225" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    72” Diagonal up to 225” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Easy snap on screen surface - Unity White Black Backed PVC - Gain 1.0
  • Borders

    As per frame system - 80mm wide
  • Frame

    Black Powdercoat Finish for Increased Contrast and Overscan Protection
  • Brackets

    MultiTech Wall Brackets
  • Options

    Flocke frame optional

CinemaSnap - Matrix White

Sizes 72" - 180" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    72” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Easy snap on screen surface - Matrix White Grey Backed PVC - Gain 1.1
  • Borders

    As per frame system - 80mm wide
  • Frame

    Black Flock Finish for Increased Contrast and Overscan Protection
  • Brackets

    MultiTech Wall Brackets

CinemaSnap - Hi-Contrast Grey

Sizes 72" - 225" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    72” Diagonal up to 225” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Easy snap on screen surface - Hi Contrast Grey Black Backed - Gain 0.8
  • Borders

    As per frame system - 80mm wide
  • Frame

    Black Powdercoat Finish for Increased Contrast and Overscan Protection
  • Brackets

    MultiTech Wall Brackets
  • Options

    Flocke frame optional

CinemaSnap - Micro-Perforated

Sizes 72" - 180" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    72” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Easy snap on screen surface - Micro-Perforated - Gain 0.95
  • Borders

    As per frame system - 80mm wide
  • Frame

    Flock Finish for Increased Contrast and Overscan Protection
  • Brackets

    MultiTech Wall Brackets
  • Options

    Matt Black Powder Coat Frame (Flocke Standard)

CinemaSnap - Rear Projection

Sizes 72" - 180" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    72” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Easy snap on screen surface - Rear Projection
  • Borders

    As per frame system - 80mm wide
  • Frame

    Black Powdercoat Finish for Increased Contrast and Overscan Protection
  • Brackets

    MultiTech Wall Brackets
  • Options

    Flocke Frame Optional

CinemaSnap - Matrix Woven

Sizes 84" - 180" diagonal
  • Description

    Fixed Frame Screen - ready to assemble - best possible lay-flat qualities
  • Sizes

    84” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Acoustic woven surface
  • Borders

    As per frame system - 80mm wide
  • Frame

    Aluminum construction with black flocked frame for projector overscan reduction
  • Brackets

    MultiTech Wall Brackets
  • Options

    Also available on request in 2.37:1, 2.39:1 and 2.40:1

  • Specifications

    CinemaSnap - Unity White PVC

    Sizes 72" - 225" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
    (mm)
    1207219721100 x 14654:3
    1208419841280 x 17054:3
    1209619961460 x 19504:3
    12100191001525 x 20354:3
    12110191101676 x 22354:3
    12115191151755 x 23404:3
    12120191201830 x 24404:3
    12130191301980 x 26404:3
    12150191502285 x 30504:3
    12160191602440 x 32504:3
    12170191702590 x 34554:3
    12180191802745 x 36604:3
    12200192003050 x 40654:3
    12225192253430 x 45704:3
    120722972895 x 159516:9
    1208429841045 x 186016:9
    1209229921145 x 203516:9
    1209629961195 x 212516:9
    12100291001245 x 221516:9
    12110291101370 x 243516:9
    12115291151430 x 254516:9
    12125291251555 x 277016:9
    12130291301615 x 288016:9
    12135291351680 x 299016:9
    12140291401740 x 310016:9
    12140291802240 x 398516:9
    12200292002490 x 442516:9
    12225292252800 x 498016:9
    120726972970 x 155016:10
    1208469841130 x 181016:10
    1209269921240 x 198016:10
    1209669961295 x 207016:10
    12100691001345 x 215516:10
    12110691101480 x 237016:10
    12120691201615 x 258516:10
    12130691301750 x 288016:10
    12140691401885 x 301516:10
    12150691502020 x 323016:10
    12160691602155 x 345016:10
    12170691702290 x 366516:10
    12180691802425 x 388016:10
    12200692002690 x 431016:10
    12225692253030 x 485016:10


    CinemaSnap - Matrix White

    Sizes 72" - 180" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
    (mm)
    1207216721100 x 14654:3
    1208416841280 x 17054:3
    1209619961460 x 19504:3
    12100161001525 x 20354:3
    12115161151755 x 23404:3
    12120161201830 x 24404:3
    12130161301980 x 26404:3
    120722672895 x 159516:9
    1208426841045 x 186016:9
    1209226921145 x 203516:9
    1209626961195 x 212516:9
    12100261001245 x 221516:9
    12110261101370 x 243516:9
    12115261151430 x 254516:9
    12120261201495 x 265516:9
    12125261251555 x 277016:9
    12130261301615 x 288016:9
    12135261351680 x 299016:9
    12140261401740 x 310016:9
    12150261501865 x 332016:9
    120726672970 x 155016:10
    1208466841130 x 181016:10
    1209266921240 x 198016:10
    1209666961295 x 207016:10
    12100661001345 x 215516:10
    12110661101480 x 237016:10
    12120661201615 x 258516:10
    12130661301750 x 288016:10
    12140661401885 x 301516:10
    12150661502020 x 323016:10
    120844684835 x 19652.35:1
    120924692915 x 21552.35:1
    120964696955 x 22452.35:1
    1210046100995 x 23402.35:1
    12110461101095 x 25752.35:1
    12120461201195 x 28102.35:1
    12130461301295 x 30452.35:1
    12140461401395 x 32802.35:1
    12150461501495 x 35152.35:1
    12160461601595 x 37502.35:1
    12170461701695 x 39802.35:1
    12180461801795 x 42152.35:1


    CinemaSnap - Hi-Contrast Grey

    Sizes 72" - 225" diagonal

    Introducing The ElectriCinema Hi Contrast Grey

    When you don’t have full control of ambient light conditions, grey assists the projector in improving black in the spectrum by shifting the contrast band towards the darker scale. This improves overall colour saturation, but with the loss of some brightness normally well compensated for by today’s projectors.

    ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
    (mm)
    1207218721100 x 14654:3
    1208418841280 x 17054:3
    1209618961460 x 19504:3
    12100181001525 x 20354:3
    12110181101676 x 22354:3
    12115181151755 x 23404:3
    12120181201830 x 24404:3
    12130181301980 x 26404:3
    12140181402135 x 28454:3
    12150181502285 x 30504:3
    12160181602440 x 32504:3
    12170181702590 x 34554:3
    12180181802745 x 36604:3
    12200182003050 x 40654:3
    120722872895 x 159516:9
    1208428841045 x 186016:9
    1209228921145 x 203516:9
    1209628961195 x 212516:9
    12100281001245 x 221516:9
    12110281101370 x 243516:9
    12115281151430 x 254516:9
    12120281201495 x 265516:9
    12125281251555 x 277016:9
    12130281301615 x 288016:9
    12135281351680 x 299016:9
    12140281401740 x 310016:9
    12150281501865 x 332016:9
    12160281601995 x 354516:9
    12170281702115 x 376516:10
    12180281802240 x 398516:10
    12200282002490 x 442516:10
    12225282252800 x 498016:10
    120726872970 x 155016:10
    1208468841130 x 181016:10
    1209268921240 x 198016:10
    1209668961295 x 207016:10
    12100681001345 x 215516:10
    12110681101480 x 237016:10
    12120681201615 x 258516:10
    12130681301750 x 288016:10
    12140681401885 x 301516:10
    12150681502020 x 323016:10
    12160681602155 x 345016:10
    12170681702290 x 366516:10
    12180681802425 x 388016:10
    12200682002690 x 431016:10
    12225682253030 x 485016:10


    CinemaSnap - Micro-Perforated

    Sizes 72" - 180" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
    (mm)
    1207213721100 x 14654:3
    1208413841280 x 17054:3
    1209613961460 x 19504:3
    12100131001525 x 20354:3
    12110131101676 x 22354:3
    12115131151755 x 23404:3
    12120131201830 x 24404:3
    12130131301980 x 26404:3
    12150131502285 x 30504:3
    120722372895 x 159516:9
    1208423841045 x 186016:9
    1209223921145 x 203516:9
    1209623961195 x 212516:9
    12100231001245 x 221516:9
    12110231101370 x 243516:9
    12115231151430 x 254516:9
    12125231251555 x 277016:9
    12130231301615 x 288016:9
    12135231351680 x 299016:9
    12140231401740 x 310016:9
    12180231802240 x 398516:9
    120726372970 x 155016:10
    1208463841130 x 181016:10
    1209263921240 x 198016:10
    1209663961295 x 207016:10
    12100631001345 x 215516:10
    12110631101480 x 237016:10
    12120631201615 x 258516:10
    12130631301750 x 288016:10
    12140631401885 x 301516:10
    12150631502020 x 323016:10
    120844384835 x 19652.35:1
    120924392915 x 21552.35:1
    120964396955 x 22452.35:1
    1210043100995 x 23402.35:1
    12110431101095 x 25752.35:1
    12120431201195 x 28102.35:1
    12130431301295 x 30452.35:1
    12140431401395 x 32802.35:1
    12150431501495 x 35152.35:1
    12160431601595 x 37502.35:1
    12170431701695 x 39802.35:1
    12180431801795 x 42152.35:1


    CinemaSnap - Rear Projection

    Sizes 72" - 180" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
    (mm)
    1207215721100 x 14654:3
    1208415841280 x 17054:3
    1209615961460 x 19504:3
    12100151001525 x 20354:3
    12115151151755 x 23404:3
    12120151201830 x 24404:3
    12130151301980 x 26404:3
    12150151502285 x 30504:3
    12180151802745 x 36604:3
    1208425841045 x 186016:9
    1209225921145 x 203516:9
    1209625961195 x 212516:9
    12100251001245 x 221516:9
    12115251151430 x 254516:9
    12120251201495 x 264416:9
    12125251251555 x 277016:9
    12130251301615 x 288016:9
    12135251351680 x 299016:9
    12150251401740 x 310016:9
    1208465841130 x 181016:10
    1209265921240 x 198016:10
    1209665961295 x 207016:10
    12100651001345 x 215516:10
    12110651101480 x 237016:10
    12120651201615 x 258516:10
    12130651301750 x 288016:10
    12140651401885 x 301516:10
    12150651502020 x 323016:10
    12180651802425 x 388016:10


    CinemaSnap - Matrix Woven

    Sizes 84" - 180" diagonal

    The new Matrix Woven acoustic surface is now available and ready for sale. Designed, built and finished on site at Moss Vale this surface provides the best possible audio solution when speakers are placed behind the projection screen. This surface is wide enough that it does not require any welds and provides the ultimate home theatre experience. Sizes above 110’’ normally require a center brace however, the Matrix Woven CinemaSnaps comes with 2 braces allowing for speakers to be placed at the back of the screen in the center, left and right. Our novel spring design tensions the Matrix Woven surface allowing for easy install and never requires surface re-tensioning!

    ITEM NOINCH DIAGONALIMAGE SIZEWEIGHTFORMAT
    (mm)(kg)
    120842784"1045 x 18601616:9
    120922792"1145 x 20351716:9
    120962796"1195 x 21251816:9
    1210027100"1245 x 22151916:9
    1211027110"1370 x 24352116:9
    1212027120"1495 x 26552316:9
    1213027130"1615 x 28802516:9
    1214027140"1740 x 31002716:9
    1215027150"1865 x 33203016:9
    1216027160"1995 x 35453216:9
    1217027170"2115 x 37653316:9
    1218027180"2240 x 39853416:9
    1219027190"2365 x 42053616:9
    1220027200"2490 x 44253816:9
    1221027210"2615 x 46504016:9
    120844784"835 x 1965182.35:1
    120924792"915 x 2155192.35:1
    120964796"955 x 2245202.35:1
    1210047100"995 x 2340222.35:1
    1211047110"1095 x 2575232.35:1
    1212047120"1195 x 2810252.35:1
    1213047130"1295 x 3045262.35:1
    1214047140"1395 x 3280282.35:1
    1215047150"1495 x 3515302.35:1
    1216047160"1595 x 3750322.35:1
    1217047170"1695 x 3980332.35:1
    1218047180"1795 x 4215342.35:1
    1219047190"1895 x 4455352.35:1
    1220047200"1995 x 4690362.35:1
    1221047210"2095 x 4915382.35:1

  • Downloads

    Specifications

    PDF (3.0MB)

    DOWNLOAD
