ElectriCinema Premium Motorised
Large Venue Screen

  • Pic 1

  • Pic 2

Market Segments

Suitable for Corporate Events
Suitable for Education use
Suitable for Government use
Suitable for Hotels
Suitable for Theatre use
Suitable for use in places of Worship

The premium projection screen of choice

Sizes 200" - 375" diagonal

The ElectriCinema has long been the premium projection screen of choice in the AV industry, with all the high quality features that you expect from a Screen Technics product: rugged design, contemporary good looks, and ease of installation with the universal bracket system.

Benefits include:

  • Integrated with Connect IP
  • 12V trigger
  • Contact closure and IR
  • Ability to link and group switch with other Connect control devices
Where to Buy

ElectriCinema - Large Venue Screen - Type D

Sizes 200" - 300" diagonal

  • Description

    Designer Style Motorised Projection Screen with Intergrated IP, 12v Trigger, contact closure & IR Remote Controlv Trigger and Link Switching to other Connect controlled devices

  • Headbox

    Colour to be specified at time of order, standard powder coat options are White or Black. Custom colours are available upon request

  • Sizes

    200” to 300” Diagonally, Custom Sizes & Formats available upon request

  • Surface

    Fire rated welded Unity White front projection surface (not black backed) - Gain 1.0
    Refer to screen material options for additional surface options

  • Roller Diameter

    150mm Heavy Duty

  • Border

    50mm Sides & bottom with adjustable top black leader. Leader length needs to be specified at time of order. Standard is 300mm. Any extra top leader must be used if ordered as layflat will be affected.

  • Brackets

    Load Rated M10 Eyebolts

  • Options

    Extra Top Masking - RF RTS Remote or 4 Core Wall Switch
    Custom powder coat colour
    Power 240 volt single phase 4 Amps

ElectriCinema - Large Venue Screen - Type E

Sizes 300" - 375" diagonal

  • Description

    Designer Style Motorised Projection Screen with Intergrated IP, 12v Trigger, contact closure & IR Remote Control

  • Headbox

    Colour to be specified at time of order, standard powder coat options are White or Black. Custom colours are available upon request

  • Sizes

    300” to 375” Diagonally, Custom Sizes & Formats available upon request

  • Surface

    Fire rated welded Unity White PVC - Gain 1.0
    Refer to screen material otions for additional surface options

  • Roller Diameter

    225mm Heavy Duty

  • Border

    50mm Sides & bottom with adjustable top black leader. Leader length needs to be specified at time of order. Standard is 300mm. Any extra top leader must be used if ordered as layflat will be affected.

  • Brackets

    Load Rated M10 Eyebolts

  • Options

    Extra Top Masking - RF RTS Remote or 4 Core Wall Switch
    Custom powder coat colour
    Power 240 volt single phase 4 Amps

  • Specifications

    ElectriCinema - Large Venue Screen - Type D - Unity White

    Sizes 200" - 300" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMATHEADBOX SIZEAPPROX. WEIGHT
    (mm)(mm)(kg)
    0620019-D200''3050 x 4065Video 4:34615135.0
    0622519-D225"3430 x 4570Video4:35120145.0
    0625019-D250''3810 x 5080Video 4:35630160.0
    0627519-D275''4190 x 5590Video 4:36140170.0
    0630019-D300''4570 x 6100Video 4:36650185.0
    0620029-D200''2490 x 4425HDTV 16:94975140.0
    0622529-D225''2800 x 4980HDTV 16:95530155.0
    0625029-D250''3115 x 5535HDTV 16:96085170.0
    0627529-D275''3425 x 6085HDTV 16:96635185.0
    0620069-D200''2695 x 431016:104860140.0
    0622569-D225''3030 x 485016:105400150.0
    0625069-D250''3365 x 538516:105935165.0
    0627569-D275''3705 x 592516:106475180.0

    ElectriCinema - Large Venue Screen - Type E - Matt White

    Sizes 300" - 375" diagonal

    ITEM NOINCH DIAGONALIMAGE SIZEFORMATHEADBOX SIZEAPPROX. WEIGHT
    (mm)(mm)(kg)
    0630019-E300''4570 x 6100Video 4:36650235.0
    0632519-E325"4955 x 6605Video 4:37155250.0
    0635019-E350''5330 x 7110Video 4:37660270.0
    0637519-E375''5715 x 7620Video 4:38170285.0
    0630029-E300''3735 x 6640HDTV 16:97190250.0
    0632529-E325''4050 x 7195HDTV 16:97745275.0
    0635029-E350''4355 x 7745HDTV 16:98295290.0
    0637529-E375''4670 x 8300HDTV 16:98850310.0
    0630069-E300''4040 x 646516:107015245.0
    0632569-E325''4380 x 700516:107555265.0
    0635069-E350''4715 x 754016:108090285.0
    0637569-E375"5050 x 808016:108630300.0

  • Downloads

    Specifications - Type D

    PDF (1.2MB)

    DOWNLOAD

    Specifications - Type E

    PDF (2.4MB)

    DOWNLOAD
