CinemaSnap 235 Side Masking Screen

Pic 1

Pic 2

For your home theatre there is nothing that compares with the perfect lay flat of a fixed frame screen and the Matrix White or Micro Perforated surface delivers the additional resolution and colour saturation that has become an industry hallmark for cinema perfection. Combined with 235 side masking, you have the best home theatre solution available.

Market Segments

Suitable for Home Entertainment

The best home theatre solution available

Sizes 84" - 180" diagonal

The ultimate home theatre experience is Cinemascope, just as the movie studios intended. With the new CinemaSnap 235 you can have the best of both worlds: 2.35:1 Cinemascope for DVDs, and, by using the motorised side masking system, reshape the screen to 16:9 HDTV for widescreen TV broadcasts.

2.35:1 Cinemascope to 16:9 HDTV at the push of a button. Designed to work with projectors that use anamorphic lens technology.

Benefits include:

  • Original movie aspect ratio 2.35:1
  • Integrated side masking for 16:9
  • Perfect lay flat
  • Flush sitting masking, with no shadow-line

CinemaSnap 235 with Side Masking - Matrix White

Sizes 84" - 180" diagonal
  • Description

    Wall mounted screen system with side masking for dual format Cinemascope to HDTV formats
  • Sizes

    84” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Hi Res Matrix White Gain 1.1
  • Frame

    Aluminium constructions with Flocked frame for projector over-scan reduction

CinemaSnap 235 with Side Masking - Micro Perforated

Sizes 84" - 180" diagonal
  • Description

    Wall mounted screen system with side masking for dual format Cinemascope to HDTV formats
  • Sizes

    84” Diagonal up to 180” Diagonal
    Custom Sizes & Formats available upon request
  • Surface

    Micro Perforated Gain 0.95
  • Frame

    Aluminium constructions with Flocked frame for projector over-scan reduction

Specifications

CinemaSnap 235 with Side Masking - Matrix White

Sizes 84" - 180" diagonal

ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
(mm)
570844684"835 x 1965/1485Cinemascope 2.35:1
570924692"915 x 2155/1625Cinemascope 2.35:1
570964696"955 x 2245/1700Cinemascope 2.35:1
5710046100"995 x 2340/1770Cinemascope 2.35:1
5711046110"1095 x 25751950Cinemascope 2.35:1
5712046120"1195 x 2810/2125Cinemascope 2.35:1
5713046130"1295 x 3045/2305Cinemascope 2.35:1
5714046140"1395 x 3280/2480Cinemascope 2.35:1
5715046150"1495 x 3515/2660Cinemascope 2.35:1
5716046160"1595 x 3750/2835Cinemascope 2.35:1
5717046170"1695 x 3980/3015Cinemascope 2.35:1
5718046180"1795 x 4215/3190Cinemascope 2.35:1


CinemaSnap 235 with Side Masking - Micro Perforated

Sizes 84" - 180" diagonal

ITEM NOINCH DIAGONALIMAGE SIZEFORMAT
(mm)
570844384"835 x 1965/1485Cinemascope 2.35:1
570924392"915 x 2155/1625Cinemascope 2.35:1
570964396"955 x 2245/1700Cinemascope 2.35:1
5710043100"995 x 2340/1770Cinemascope 2.35:1
5711043110"1095 x 25751950Cinemascope 2.35:1
5712043120"1195 x 2810/2125Cinemascope 2.35:1
5713043130"1295 x 3045/2305Cinemascope 2.35:1
5714043140"1395 x 3280/2480Cinemascope 2.35:1
5715043150"1495 x 3515/2660Cinemascope 2.35:1
5716043160"1595 x 3750/2835Cinemascope 2.35:1
5717043170"1695 x 3980/3015Cinemascope 2.35:1
5718043180"1795 x 4215/3190Cinemascope 2.35:1

Downloads

CinemaSnap-235-Side-Masking-Screen-Install-Instructions.pdf

Specifications

PDF (0.9MB)

DOWNLOAD

Install Instructions

PDF (1.6MB)

DOWNLOAD
