ElectriCinema 235 In-ceiling Screen
with Side Masking

Pic 1

Market Segments

Suitable for Corporate Events
Suitable for Education use
Suitable for Government use
Suitable for use in Hotels
Suitable for Theatre use
Suitable for use in places of Worship

ElectriCinema 235 - In Ceiling Screen with Side Masking - Unity White PVC

Sizes 84" - 150" diagonal
  • Description

    In-ceiling screen system with side masking for dual format Cinemascope to HDTV formats

  • Headbox

    MDF constructions with fully painted white underside & ceiling edge covers for easy install

  • Sizes

    84” to 150” Diagonally, Custom Sizes & Formats available upon request

  • Surface

    Side tensioned Unity White black backed PVC - Gain 1.0
    or
    Side tensioned Hi-Contrast Grey black backed - Gain 0.8

  • Roller Diameter

    80mm Heavy Duty

  • Border

    50mm Sides & 100mm Bottom with 500mm adjustable top black leader

  • Top Leader

    For sizes 100” and under the maximum total top black leader available is 500mm, for screen sizes over 100”
    The maximum top black leader available is 600mm

  • Options

    Extra top masking
    Underside paint colours

Designed to work with projectors that use anamorphic lens technology

Sizes 84" - 150" diagonal

With the ElectriCinema 235 you can have the best of both worlds: 2.35:1 Cinemascope for DVDs, and, by using the motorised side masking system, reshape the screen to 16:9 HDTV for widescreen TV broadcasts.

Supplied as an integrated in-ceiling solution, with a painted underside and ceiling edge trims for a single trade install.

Benefits include:

  • Original movie aspect ratio 2.35:1
  • Integrated side masking for 16:9
  • One-piece in-ceiling design
  • Flush sitting masking, with no shadow-line
  • Industry leading CONNECT control system
  • Allows IR control or contact close for integration with control systems
  • Links with other CONNECT devices, such as projector lifts or roller blind systems
  • Side tensioned surface for the best possible layflat

Specifications

ElectriCinema - In-ceiling Screen with Side Masking - Unity White PVC

Sizes 84" - 150" diagonal

ITEM NOINCH DIAIMAGE SIZE 2.35:1IMAGE SIZE 16:9FORMATBOX LENGTHBOX HEIGHTBOX DEPTHWEIGHT
(mm)(mm)(mm)(mm)(mm)(kg)
560844984"835 x 1965835 x 1485Cinemascope 2.35:1254525029080.0
560924992"915 x 2155915 x 1625Cinemascope 2.35:1273525029085.0
560964996"'955 x 2245955 x 1700Cinemascope 2.35:1282525029090.0
5610049100"995 x 2340995 x 1770Cinemascope 2.35:1292025029095.0
5611049110''1095 x 25751095 x 1950Cinemascope 2.35:13155250290100.0
5612049120"1195 x 28101195 x 2125Cinemascope 2.35:13390250290110.0
5613049130"1295 x 30451295 x 2305Cinemascope 2.35:13625250290115.0
5614049140"1395 x 32801395 x 2480Cinemascope 2.35:13860250290125.0
5615049150''1495 x 35151495 x 2660Cinemascope 2.35:14095250290130.0


ElectriCinema - In-ceiling Screen with Side Masking - Hi Contrast Grey

Sizes 84" - 150" diagonal

Introducing The ElectriCinema Hi Contrast Grey

When you don’t have full control of ambient light conditions, grey assists the projector in improving black in the spectrum by shifting the contrast band towards the darker scale. This improves overall colour saturation, but with the loss of some brightness normally well compensated for by today’s projectors.

ITEM NOINCH DIAIMAGE SIZE 2.35:1IMAGE SIZE 16:9FORMATBOX LENGTHBOX HEIGHTBOX DEPTHWEIGHT
(mm)(mm)(mm)(mm)(mm)(kg)
560844884"835 x 1965835 x 1485Cinemascope 2.35:1254525029080
560924892"915 x 2155915 x 1625Cinemascope 2.35:1273525029085
560964896"'955 x 2245955 x 1700Cinemascope 2.35:1282525029090
5610048100"995 x 2340995 x 1770Cinemascope 2.35:1292025029095
5611048110''1095 x 25751095 x 1950Cinemascope 2.35:13155250290100
5612048120"1195 x 28101195 x 2125Cinemascope 2.35:13390250290110
5613048130"1295 x 30451295 x 2305Cinemascope 2.35:13625250290115
5614048140"1395 x 32801395 x 2480Cinemascope 2.35:13860250290125
5615048150''1495 x 35151495 x 2660Cinemascope 2.35:14095250290130

Downloads

Specifications

PDF (2.7MB)

DOWNLOAD

Install Instructions

PDF (0.7MB)

DOWNLOAD

Surface Replacement Instructions

PDF (0.7MB)

DOWNLOAD

Replacement Surface Unpacking Instructions

PDF (0.2MB)

DOWNLOAD
